• EQ901 Elite Equalizers for BOSE 901 Series I/II, III/IV or V/VI

    $298.00

    This item is out of stock


    Coming Soon

    Please contact us if you would like to be an evaluation customer


    Introduction


    The EQ901 Elite Series is an ultra high performance replacement for existing BOSE 901 Series I/II, III/IV or V/VI equalizers (select your series when ordering).

    The EQ901 Elite provides the BOSE 901 specific equalizer curves with four tone modes designed to accommodate a wide range room conditions and recording variations.

    The EQ901 Elite is intended to be used with high quality pre/power amplifiers or integrated amplifiers, and receivers.  The EQ901 Elite is our flagship equalizer building on our EQ901B series with lower distortion, greater dynamic range and higher fidelity made possible audiophile grade digital signal processors, DACs and analog signal stages.



    EQ901 Elite Features


    • The EQ901 Elite Series features four specifically designed equalization curve sets unique to each Series I/II, III/IV or V/VI (select your series when ordering)

    • Precise 901 equalization is performed digitally in an Analog Devices 400MHz SHARC DSP processor with 24 bit resolution

    • Two identical stereo pairs outputs are available allowing for dual active stereo systems (two stereo power amps) or the addition of an active subwoofer(s)

    • Remote selectable tone mode settings:

    1.    Normal mode

    2.    Enhanced mode

    3.    Warm mode

    4.    Low frequency reduction mode

    • Remote control for selecting the four tone modes (Normal, Enhanced, Warm and LF reduction)

    • Ultra low distortion 2 Vrms output driver stage

    • Selectable input sensitivity of 2 Vrms or 4 Vrms

    • Proven reliability


     What’s Included


    • EQ901 Elite equalizer for your BOSE 901 Series I/II, III/IV or V/VI (select your series when ordering)

    • Four precision engineered tone mode equalization curves

    • IR Remote Control for tone mode selection

    • External power supply


    Tape/Processor Loop Set Up



    Pre/Power Amplifier Set Up

    Hardware Installation


    When audio input and output connections are being made, be sure that all associated equipment is powered off.  When you power the EQ901 Elite on and off be sure that associated equipment is off first. Connect power to the EQ901 Elite before turning associated equipment on.


    Remote Control Functions


    Tone modes are  selected on the remote control:



    1.    Normal mode

    2.    Enhanced mode

    3.    Warm mode

    4.    Low frequency reduction



    Selecting Tonal Characteristics Modes


    Selection of the tone mode is generally a subjective choice based on what sounds best to you.  Specifically: Normal mode is the most neutral, Enhanced mode provides a richer sound with more treble and bass, Warm mode adds midrange with slight treble reduction, and Low frequency reduction mode is intended to control bass in smaller rooms or on boomy recordings .


    Specifications


    • EQ901 Elite platform base: miniDSP 2x4 HD

    • Digital Signal Processor Engine: Analog Devices Fixed point DSP SHARC ADSP-21489

    • USB controller: XMOS xCORE-200

    • Digital to Analog Converter (DAC): AK4626A

    • Internal Processing resolution & Sample rate: 32 bit / up to 192 kHz

    • Audio Input/Output Connectivity:  Unbalanced output, RCA

    • Input / Output Max Levels: In 2Vrms / 4Vrms (jumper-selectable), Out 2Vrms

    • Input Impedance: 10 k Ω

    • Output Impedance: 560 Ω

    • Filtering Technology: FIR + I/IIR

    • Dimensions: 27 x 119 x 107 mm

    • Power: 12V DC single supply, 2.1 mm round plug, 2.5Watt

    • IR Remote: miniDSP Remote



    Analog Input Level


    The analog audio input levels are switchable between 2 and 4 Vrms to accommodate use with most equipment.  The EQ901 Eite is shipped with the analog input level set to 2 Vrms.


    Support


    • 30 day 100% satisfaction guarantee

    • Installation guide and phone support

    • Deer Creek Audio is an authorized miniDSP dealer

    • One year full replacement warranty



    Warranty Terms


    This product is warranted to be free from defects in materials and workmanship for a period of one year from invoice.  Warranty does not cover failure of the product due to incorrect connection or installation, improper or undocumented use, unauthorized servicing, modification or alteration of the unit in any way, or any usage outside of that recommended in this manual.  The customer provides return shipping to Deer Creek Audio. Deer Creek Audio is an Authorized miniDSP dealer.
