The EQ901B-V/VI is a direct replacement for existing BOSE 901 ® Series V/VI equalizers providing improved clarity, imaging and range. The EQ901B-III/IV features dual equalization curves, normal and enhanced, which will accommodate your Series V/VI depending on personal preference.

The EQ901B-V/VI installs in your tape monitor loop, pre-out/pre-in loop, or between your pre-amp and power-amp. Switchable input levels between 0.9 Vrms and 2 Vrms accommodates use with most preamplifiers, amplifiers, or receivers.

Features Summary:

Precision Engineered BOSE 901 ® Series V/VI Equalization

Dual equalization curves, normal and enhanced
Ultra Low Noise & Proven Reliability
The EQ901B-V/VI is based on the miniDSP 2x4 digital signal processor

What’s Included:

EQ901B-V/VI Equalizer
Precision frequency equalization curves optimized for BOSE 901 ® Series V/VI
Regulated power supply

User Guide

Tone Controls:

The EQ901B-V/VI has been calibrated to provide a neutral and natural sound without tone control adjustments
There are no external tone controls on the EQ901B-V/VI , your audio/video receiver or amplifier tone controls are used to make fine adjustments

The EQ901B-V/VI includes a 48dB/Octave subsonic (rumble) filter

Specifications:

Distortion <1% THD at maximum input
Dynamic range: un-weighted >98dB
Analog Devices ADAU1701 digital signal processor (DSP) Engine
Dimensions: 26h x 107w x 94d mm

Support:

One year full replacement warranty
30 day 100% satisfaction guarantee

Installation guide and phone support
Deer Creek Audio is an authorized miniDSP dealer

Recommended accessories:

Global precision regulated AC/DC power supply for :Europe, U.K., Australia and others, plug types: B, C, G, I
RCA Cables - Two (2) Pairs, Excellent quality, flexibility, Shielded, High Fidelity

EQ901B-V/VI User Guide
