Hypex nc252 Quad Amplifier

In stock
Ships same business day - FedEx or UPS

The nc252 Quad Amplifier from Hypex provides four channels of high performance Class D power, combining extreme performance with a compact profile.  This is the perfect amplifier for a bi-amplified system, multi-channel home theater application or two-way active design.

These units are a pure Hypex engineered design, with all components sourced directly from Hypex or an approved OEM.  The heavy machined aluminum case is the proven Hypex design, ensuring proper heat dissipation within a modern, sleek profile.

Our entire line of Hypex amplifiers compete with similar high-end products, providing serious sound for a fraction of the price.  Assembled and tested by Deer Creek Audio, each amplifier is shipped with individual printed test results.

Features

• NCore NC252MP Class D amplifier modules
• Differential inputs with high common-mode impedance
• Overcurrent protection
• Supply overvoltage / undervoltage protection on all rails
• 2Ω stable for use with a wide range of speakers

Specifications

• THD+N:  0.006% (-100 dB)  20 - 20.000 Hz
• Max Output Power:  1 kHz, THD=1%, all channels driven, per channel
• 150 W rms at 8Ω
• 250 W rms at 4Ω
• 180 W rms at 2Ω
• Frequency response:  10 - 20 kHz +/- 0.5dB
• Output noise:  9.5µV @ 10 - 20 kHz AES17
• Gain:  25.5 dB
• Signal to Noise:  121 dB
• Input Impedance:  47 kΩ
• Idle power:  27 W, all 4 channels active (6.75 W per channel)

Highlights

• High efficiency
• Ultra-low noise
• Wide bandwidth
• Excellent ripple rejection
• Low, load-independent output impedance
• Flat, fully load-independent frequency response
• Very low, frequency independent THD

Dimensions

• 12.25 inches (width)
• 4.0 inches (height)
• 12.0 inches (depth)

What’s Included

• Assembled amplifier
• Printed test results
• Power cord
• User guide
• Tool for cover removal

Support

• U.S. technical support through Deer Creek Audio
• Deer Creek Audio is an authorized Hypex dealer

Warranty Terms

Hypex warranty is five years or 20,000 hours.  The first year, parts and labor are provided by Deer Creek Audio in the United States.  Remaining warranty coverage is provided directly through Hypex in The Netherlands.

This product is warranted to be free from defects in materials and workmanship for a period of one year from invoice. Warranty does not cover failure of the product due to incorrect connection or installation, improper or undocumented use, unauthorized servicing, modification or alteration of the unit in any way, or any usage outside of that recommended in the product manual. The customer provides return shipping to Deer Creek Audio. Deer Creek Audio is an authorized Hypex dealer.

Shipping

Orders received by 2 PM mountain time are shipped the same business day. U.S. domestic orders ship for $24.95. Orders shipping to Canada are $44.95. For more details check out the FAQs on Buying from Deer Creek Audio.
